18L Table Top Dental Steam Sterilizer Autoclave | TR250N

18L Table Top Dental Steam Sterilizer Autoclave

SPECIFICATION

Sterilization Class	CLASS N
Sterilizing Temperature	122℃ / 251.6℉ & 132℃ / 269.6℉
Chamber Dimension	Ø250 x D350mm / Ø9.84″ x D13.78″
Display	High-light LED tube display
Input	110V, 60HZ, 900VA
Control Precision	Temperature: 1℃ / 33.8℉
Pressure: 0.1bar
Safety System	Relief valve
Hand lock door
Pressure or temperature over load protection
Alarm system
Tray Holder	3 layers tray
Chamber	Medical stainless steel 304
Max working pressure:2.3bar
Min working pressure: -0.9bar
Max temperature: 145℃ / 293℉
Dimension	56cm x 39cm x 36cm / 22″ x 15″ x 14″
Weight	25kgs / 55lbs
Operation Temperature	5～40℃ / 41℉～104℉
Noise	<50db

PROGRAM

PROGRAM Temp.	Pressure	Sterilization Time
134℃/ 273.2℉	2.2bar	5mins
121℃ / 249.8℉	1.2bar	25mins

Application Field

Dental Clinic, Hospital, First-aid Station, Laboratory, Veterinary hospital, Beauty Parlor, Tattoo House…

Quality System

Quality System No.	Quality System Name
ISO 9001	Quality management systems—Requirements
ISO 13485	Medical device-Quality management systems-Requirement for regulatory purposes

Certification

ISO 9001

Steam Sterilizer CE

Sterilizer Chamber CE

Application Directive and Standard

Directive or Standard No.	Directive or Standard Name
MDD 93/42/EEC	Medical Device Directive
PED 97/23/EC	Pressure Equipment Directive
EN 61010-1	Safety regulations for electrical measuring, controlling and laboratory Devices- Part 1: General requirements
EN 61010-2-040:	Safety requirements for electrical equipment for measurement, control and laboratory use —Part 2-040: Particular requirements for sterilizers and washer-disinfectors used to treat medical materials
EN 13060	Small steam sterilizers
EN 61326-1	Electrical equipment for measurement, control and laboratory use – EMC requirements

Product Information

Technical Detail

Model	TR250N Basic model
Chamber capacity	Ø250XD350mm / Ø9.84″ x D13.78″
Inside capacity	18 Liter
Outside size (L x W x H)CM	56 x 39 x 36CM / 22″ x 15″ x 14″
Packing Size (L x W x H)CM	63 x 46 x 41CM / 25″ x 18″ x 16″ N.W:25KGS / 55lbs; G.W: 26KGS / 57lbs
Sterilize temperature	122℃& 134℃
Sterilize pressure(Mpa)	0.12Mpa & 0.22Mpa
Sterilize time	25Min& 6Min
Hearter	900W
Material quality	Stainless steel #304. Boiler chamber surface with burnish.
Suface deal with	The machine foundation and the shell use high temperature baking varnish processing
Electric current-110V	8A
Safety equipment	*Pressure adjustment:adjust the inter pressure.If over standard value automatic vent. *Avoid overheat protect device:When inter temperature overheat,power break electric current automatically.
Disinfection complete action	Automatic discharge of water and steam

Additional Information

ADVANTAGE

1. It has an normal open valve to release air pressure automatic.

2. This autoclave will drain water automatic after every cycle.

3. Water level sensor can effectively avoid the heater burned.

4. The digital display can show temperature instantly.

5. Error code alarm system can make users judging problem easily.
