S-4 Four Functions Hydraulic Hospital Bed

S-4 Manual bed Four Functions Hydraulic Hospital Bed

Features:

1. Bed base, frame and leg are all made of cold-rolled steel plate and tube and coated by electrostatic spray after twice phospatization.
2. Plastic coated steel headboard and footboard(steel frame with wooden board);
3. Steel net platform.
4. Central castors enable the bed to move and position flexibly, lightly and conveniently.
5. The bed is equipped with aluminum alloy side rails.

Technical Parameters:

Size: 2240*980*520-810mm
Height: 520-810mm controlled by hydraulic pedal
Backrest max upward angle: 60°, gas spring control
Trendelenburg: 12°, controlled by gear mechanic system
Anti-trendelenburg: 12°, controlled by gear mechanic system

• 4 – Function hydraulic bed with sides
• Air assisted backrest
• Hydraulic height adjustment
• Trendelenburg tilting
• Removable head and foot ends
• Folding bedsides
• Estimated dimensions 2200 x 950 x 720 mm
• Estimated weight 120 KG
• Bed height with no mattress 450 mm
• Backrest without auto-contour movement
• Heigh adjustment
• Trendelenburg tilting
• Anti-Trendelenburg tilting
• Mesh-wire bed platform, good for vitalization to prevent mattress from mold
• Trendelenburg and reverse Trendelenburg position is controlled by gear mechanism system

DOSE NOT COME ASSEMBLED
