Description

Characteristics:

1.Sterilizing course automatic sterilization controlled by computer, easy to operate.

2.With drying function, suitable dressing drying.

3.With over-temperature, over-pressure auto-protect device.

4.The door opening mechanism cannot be operated until the pressure in the chamber is reduced to 0.027MPa.It can’t be start on if the doesn’t closed well.

5.The safety value will be open automatically when the inner pressure over 0.24MPa, and the steam be exhausting to the water tank.

6.The power will be cut-off automatically, cut-off the water and alarm when the machine lacking water.

7.The chamber of the sterilizer is made of stainless steel.

8.With printer.

Technical data

Technical data MS-150YDB MS-200YDB MS-280YDB
Sterilizing chamber

volume

150L

φ440×1000mm

200L

φ515×1000mm

280L

φ600×1000mm

working pressure 0.22 MPa
  1. working temperature
134℃
Adjustment of temperature 40℃ – 134℃
Time of sterilization 0-99 min
Time of drying 0-99 min
Heat average ≤± 2℃
Power 9KW/380V 50Hz 9KW/380V 50Hz 12KW/380V 50Hz
Dimension 1400×650×1600 1400×750×1700 1520×910×1900
