DEFIBRILLATOR RESCUE LIFE 9

DEFIBRILLATOR RESCUE LIFE 9

Close to the needs of the modern emergency medicine, Monitor DEFIBRILLATOR RESCUE LIFE 9 guarantees a user friendly interface, an impact-proof 8.4? LCD display and a powerful battery up to 10 hours to ensure continuous monitoring. Different product configurations are available, from the standard one to the fully equipped device with all optional included. System Test and Shock test manually selectable and detailed report printed automatically to ensure readiness and top operating conditions

Technical specifications

GENERAL REQUIREMENTS

Dimension & weight

• 335 x 225 x 360 mm,
• 6,5 Kg with dual batteries Electrical: AC 100-240 VAC, 50/60 Hz
• Rechargeable dual batteries: 15.0 V 3.2 Ah Lithium-ion Battery Operation Time
• >5 hours, >10 hours with dual batteries Battery Charge Time
• Max. 3 hours Capacity
• 150 shocks with single battery or 300 shocks with dual battery at 230J fully charged Software
• Voice and texts multi language Memory
• Internal flash for ECG data, events and usage review up to 10 hours

MANUAL MODE

Energy range

• 1 – 230 J (from 1-10 J in 1 J steps; from 10 to 230 J in 10 J steps) Commands
• Multifunction trim knob. Charge and shock button directly in the front panel for hands free defibrillation Paddles
• Reusable adult & pediatric defi paddles with charge/shock command
• Disposable defi pads and internal defi paddles (optional) Operating mode
• ECG ? R ? wave synchro or async mode Indicators
• Battery and main led indicators
• Clear and visible backlight color buttons
