USE
For the examine of abdomen, heart, gynecology, obstetrics, urology, small organs, pediatrics, blood vessels, etc.
2. Monitor
High resolution 15 “LCD display.
3. Image display mode
B,2B,B+M,4B,M,B+Color,B+PDI,B+PW,B+Color+PW,B+PDI+PW,★B+C/PDI Double real time
4. Probe elements: 128
5.1 Probe specification
| Probe specification | 3.5MHz multi-frequency convex probe | 7.5MHz multi-frequency linear probe | 6.5MHz multi-frequency transvaginal probe |
| Scanning angle | 60° | / | 135° |
| elements | 80 | 80 | 80 |
| frequency scope | 2.0MHz-5.0MHz | 6.0MHz-9.0MHz | 4.5MHz-9.0MHz |
| 4 multi-frequency | 2.0/2.5/3.5/5.0 | 6.0/6.5/7.5/9.0 | 4.5/5.5/6.5/7.5 |
| Max scanning depth | ≥190mm | ≥60mm | ≥60mm |
| Blind zone | ≤5mm | ≤3mm | ≤4mm |
5.2 Operating mode
B,B/B,4B mode
M,B/M mode
CFM
PDI
PW
THI
6. Measurement / Calculation
6.1 General measurement
B Mode measurement: distance, area (distance measurement method, ellipse distance method, trace method), circumstance (distance measurement method, ellipse distance method, trace method), volume (two – axial method), angle , Histogram , sectional view, stenosis rate( length stenosis rate, area stenosis rate ) and depth.
M mode measurement: depth, slope, heart rate, circle
D mode measurement: velocity, heart rate, flow velocity, time acceleration, Pulse/ Resistance Index, Max differential pressure, PG mean,ratio, stroke volume, flow rate.
6.2 Gynecology measurement and analysis: uterus, endometrium, ovary, cervix, follicle.
6.3 Obstetric measurement and analysis
BPD),CRL,GS,FL,HL,TAD,TTD,APTD,HC,AC,EDC,FT,LV,THD,TCD,OFD,GA,EFW,LMP,AFI,and calculate GA, EFW, EDD and growth curve, different formula of many counties.
6.4 Urology measurement and analysis: Prostate volume, Residual Urine Volume
6.5 Cardiology measurement and analysis
6.6 Measurement report:
Obstetric measurement report,
gynecology measurement report,
cardiology measurement report,
urology measurement report and other measurement reports
Automatically store measurement results and generate report
Standard configuration:
| Main unit:1 pc |
| Double probe sockets, automatically identify probe; |
| 3.5MHz multi-frequency abdomen convex probe:1pc |
| 7.5MHz multi-frequency high linear probe:1pc |
| CD: 1pc |
| Reticle: 1pc |
Optional configuration:
| Video Printer(sony 897-MD) |
| 6.5MHz multi-frequency trans-vaginal prob |
